Exploring Grindr's Photo Cache

UPDATE (June 12 2022): I wrote this blog post originally in 2014 and it's highly likely that Grindr's data folder on Android doesn't look anything like this anymore. I haven't rooted my Android phones in a long time and haven't run Grindr in several years either. I sometimes get emails from people asking for help getting into their Grindr cache -- I can't help you, and don't ask me about this. This blog post is very outdated, Grindr has gone thru several complete re-designs in the last 8 years and they've probably changed everything about their data folder layout.

What you can do if you want to look into this yourself is: root your Android phone, look in your /data/data folder for Grindr's app data, copy it out to your PC and go thru it yourself. The file command on a macOS or Linux terminal can tell what type of file something is regardless of its extension (in this post, many JPEG photos were named with ".1" file extensions instead of .jpeg and Linux easily ferreted this out).

Also note that rooting your Android phone may require a factory reset of the phone, so if it's your existing Grindr cache you want to get into, you may be out of luck. Google Pixel phones for example officially support unlocking the bootloader (necessary for flashing custom ROMs and root), but this action forces a factory reset for privacy (e.g. a thief stole your phone and wants to root it, which would let them bypass your lock screen, Google wants the phone to mandatorily reset to factory defaults before it can be rooted). Some phones with shadier root exploits may not need the factory reset. You're on your own either way. Don't ask me for support in rooting your phone or helping you hack Grindr.

A long time ago, the Grindr for Android app used to store its photo cache on your SD card, but lately they hid them away in the app's private space to make them slightly more difficult to get to. I decided to go exploring using Root Browser and see what I could find out.

When I say "photo cache" I mean the place where Grindr downloads pictures locally so that it doesn't need to keep redownloading everyone's pictures all the time and consuming a lot of unnecessary bandwidth. Grindr caches both profile pictures and pictures received over chat messages. They both go into the same place. So if you have access to that place, you can get high resolution copies of all pictures received over chat and have them on your PC. :)

First of all, you'll need a rooted Android device for this, because the Android OS normally doesn't allow apps to get into each other's private data folders. The Root Browser app is a file browser that's root-aware (so it will prompt for root permission when you attempt to open a folder that ordinarily you can't open without root).

So, without further ado, Grindr's photo cache is located at /data/data/com.grindrapp.android/cache/picasso-cache/. This folder may contain a lot of files, mine had 3,458 and so Root Browser took a while to load that folder. You can copy it somewhere under /mnt/sdcard and then get to your files from a PC that way. Make sure the files are no longer owned by "root" when put in the SD card part, or you may run into issues when accessing them from your PC.

Most of the files in this folder have hexadecimal names that appear to be hashes of some sort, and the names usually come in pairs, one with a ".0" file extension and the other with a ".1", for example one I found on my phone was 4e21d675447678d0493bc8cb41a56e8d.0.

The ".0" file is a plain text file, and most of the ".1" files are the JPEG images. I use Linux, and my file browser automatically identified the types of all the files and showed thumbnail images for all the ".1" files. So, most of the time if you rename one of the ".1" files to have a ".jpg" extension you can see the images under Windows.

Some of the .1 files aren't images though. Some are more text files, and I peeked inside one to see what it was:

$ cat c1749deee81d4fece16d836e177c5852.1
[{"messageId":16970,"title":"Calling All DJs & Bartenders","body":"Are you one of the sexiest DJs or bartenders and able to work a paid event on the afternoon of April 27th in Palm Springs? If so, send us your information and a link to your website to palmsprings@grindr.com or simply tap 'More' to email us directly. ","actionTitle":"More", "dismissTitle":null, "expirationDate":1396853940000, "url":"mailto:palmsprings@grindr.com"}]

These appear to be the broadcasted pop-up messages shown in the app sometimes.

Now, the other interesting files are the ones with the ".0" extensions. These appear to be debug information, and they're basically the full HTTP request dump used to download the ".1" file. Here's what the one looked like for my profile picture (in case the Grindr CDN link stops working and you're curious, it's this picture):

$ cat 4e21d675447678d0493bc8cb41a56e8d.0
http://cdns.grindr.com:80/images/profile/1024x1024/d8dfd4eb2abd9c4d29653587cc87912b393bac97
GET
0
HTTP/1.1 200 OK
14
Accept-Ranges: bytes
Content-Length: 72057
Content-Type: image/jpg
Date: Fri, 04 Apr 2014 20:09:05 GMT
Etag: "98af07f8697f854734874296a90c640f"
Last-Modified: Sat, 01 Mar 2014 22:05:22 GMT
Server: ECS (lax/2851)
x-amz-id-2: [REDACTED]
x-amz-request-id: [REDACTED]
X-Android-Received-Millis: 1396642144430
X-Android-Response-Source: CONDITIONAL_CACHE 200
X-Android-Selected-Transport: http/1.1
X-Android-Sent-Millis: 1396642144347
X-Cache: HIT

I edited-out the "x-amz" headers because I'm not sure how secret those are supposed to be.

When browsing through my cache folder I also saw some pictures that weren't profile pics, but were sent over chat messages. These always seem to be the full resolution of the original pic sent, i.e. not thumbnails or anything. The ".0" file looks the same as for a profile picture, except the URL downloaded begins with "http://cdns.grindr.com:80/grindr/chat/" and the server headers respond with a "Content-Type: binary/octet-stream" (which causes a web browser to download the picture to disk instead of displaying it in the browser).

Some of the ".1" files are actually empty (0 bytes), and their .0 files indicate that these are the ad banners (requesting a URL from googleads.g.doubleclick.net). So it looks like whatever system in Grindr is responsible for downloading pictures also sorta deals with downloading ad banners, except it doesn't actually save the banner into the cache folder.

The last somewhat not-very-interesting file in the cache folder is called "journal", and it's a text file. By reading the first couple lines, it appears to be part of libcore.io.DiskLruCache, a bit of Java code that provides a rotating offline cache. This probably means that, if Grindr's cache folder fills up, it will automatically remove old files to make room for new ones, so it can keep its overall disk usage under control automatically. The journal file appears to list the hash names of all the other files in the folder, along with words like "CLEAN", "DIRTY", and "REMOVE".
